add-in
id:door for Autodesk® Revit®
create, add and modify doors among more than 10 preset types
10+ Door Types
- Single Hinged
- Double Hinged
- Sliding (2/3/4 – Sash)
- Single Sliding Pocket
- Double Sliding Pocket
- Single Sliding Barn
- Double Sliding Barn
- Sliding Folding (2/3/4/5/6 – Sash)
- Single Pivot
- Double Pivot
The Units that you Work
id:door adjusts to the project units. Working in decimal inches, decimal feet, feet and fractional inches, fractional inches, meters, decimeters, centimeters and millimeters.
Frame
Sets width, thickness, structural tolerance, deep from inner face, rebate width, rebate depth and frame material. Set the frame between 10 frame types (flat, rebated, stop, etc).
Leaf
Set the door leaves between 17 leaf types (flush, stile & rail, plank, etc) and 8 panel types (bevel, glass, grid, etc)
Sets stile width, bottom rail width, leaf thickness, glass thickness, and leaf material.
Add grid to your glass panel. Sets the width, thickness, number of rows and columns, and their material.
Interior & Exterior Trims
Add interior and exterior trim to your doors. Sets thickness, width, offset, upper and lower overhang and material.
Even More Features
Define the type parameters: model, keynote, build type, manufacturer, cost, type comments, descriptions, assembly code, etc. from the graphical interface of id:door when you create or modify your windows.
The different parts of the doors (Frame, Leaf, Glass, Trim, etc.) can be assigned materials independently or through the object style.
The name of the doors can be defined automatically or custom.
Doors created with id:door can be modified and edited with the same graphical interface, all their attributes can be changed including the type of door.
All door families have shared parameters that allow them to be included in schedules.
In all types of doors the opening line can be shown or hidden. Specify line weights, line colors and line patterns with the Object Styles tool. To override these project-wide settings for a particular view, use the Visibility/Graphics tool.
Change family to another all door instances or only one of them from the graphical interface of id:door.
All door families have three levels of detail: coarse, medium, and fine. Use a higher detail level as the view scale increases.
Installation / Uninstallation
The installer that ran when you downloaded this app/plug-in from Autodesk App Store will start installing the app/plug-in. Or simply double-click the downloaded installer to install the app/plugin. You may need to restart the Autodesk product to activate the app/plug-in.Uninstall through MS Windows Control Panel/Programs and Features using standard methods.
Trial version
Trial version only has two types of doors.
PAID VERSION
id:door + id:window
US$
15
/month
- +10 Doors Types
- +10 Window Types
- Imperial and Metric Units
- Parametric Frame and Sash
- Parametric Grids
- Parametric Sill and Board
- Parametric Exterior and Interior Trim
- Set Material to Each Element
- Set Type Parameters
- Show or Hide Opening Line
- Three Levels of Detail
PAID VERSION
id:door + id:window
US$
120
/year
- +10 Doors Types
- +10 Window Types
- Imperial and Metric Units
- Parametric Frame and Sash
- Parametric Grids
- Parametric Sill and Board
- Parametric Exterior and Interior Trim
- Set Material to Each Element
- Set Type Parameters
- Show or Hide Opening Line
- Three Levels of Detail
TRIAL VERSION
id:door + id:window
FREE
- 2 Door Types
- 2 Window Types
- Imperial and Metric Units
- Parametric Frame and Sash
- Parametric Grids
- Parametric Sill and Board
- Parametric Exterior and Interior Trim
- Set Material to Each Element
- Set Type Parameters
- Show or Hide Opening Line
- Three Levels of Detail
- Trial version only has two types of doors and two types of windows
